Happy April Fool’s Day to all my readers, and welcome to one web site which won’t irritate you all day with bizarre practical jokes. Instead, I bring you another edition of Friday Q&A. In this edition, I will discuss various ways of handling signals in Mac programs, a topic suggested by friend of the blog Landon Fuller.

Signals Signals are one of the most primitive forms of interprocess communication imaginable. A signal is just a small integer sent to a process. You can send a signal using the kill command, which also has a corresponding function available from C.

When a signal is delivered, it can terminate the process, pause/resume the process, be ignored, or invoke some custom code. That last option is called signal handling, and that is what I want to discuss today.

The list of defined signals can be seen in the header sys/signal.h. Many of these are used for familiar purposes. SIGINT is the signal generated when you press control-C in the shell. SIGABRT is used to kill your program when you call abort(), and SIGSEGV is the infamous segmentation fault, which pops up when you dereference a bad pointer.

Signal handling is esoteric and most programs don’t need to worry about it at all. However, there are cases where it can be useful. For terminal and server programs, it’s handy to catch SIGHUP, SIGINT, and other similar signals to do cleanup before exiting, as a sort of low-level version of Cocoa’s applicationWillTerminate:. The SIGWINCH signal is handy for sophisticated terminal applications. SIGUSR1 and SIGUSR2 are user-defined signals which you can use for your own purposes.

sigaction The lowest level interface for signal handling is the sigaction function. It provides some sophisticated and arcane options, but the important part is that it allows you to specify a function which is called when the signal in question is delivered:

1
    static void Handler(int signal)
2
    {
3
        // signal came in!
4
    }
5

6
    struct sigaction action = { 0 };
7
    action.sa_handler = Handler;
8
    sigaction(SIGUSR1, &action, NULL);

Wrong.

Reentrancy The problem is that signals are delivered asynchronously, and the function registered here is also invoked asynchronously. Code always has to run on a thread somewhere. Depending on how the signal is generated, the handler is either run on the thread that the signal is associated with (for example, a SIGSEGV handler will run on the thread that segfaulted) or it will run on an arbitrary thread in the process. The problem is that it’s essentially an interrupt in userland, and whatever code was running when it came in will be paused until the handler is done.

As anyone who was around in the classic Mac days knows, writing code that runs in an interrupt is hard. The problem is reentrancy. Many people confuse reentrancy with thread safety, but they are not the same concept, although they are somewhat similar.

Thread safety means that a particular piece of code can run on multiple threads at the same time safely. Thread safety is most commonly accomplished by using locks. A call acquires a lock, does work, releases the lock. A second thread that comes along in the middle will block until the first thread is done.

If code is reentrant that means that a particular piece of code can run multiple times on the same thread safely. This is different and considerably harder.

What if you take the thread safety approach of locking and apply it to reentrancy? The first call acquires the lock. While it’s active, the code is called again. It tries to acquire the lock, but the lock is already taken, so it blocks. However, the first call can’t run until the second call is done. The second call can’t run until the first call is done. The result is a frozen program.

Writing reentrant code is hard, and as a result very few system functions are reentrant. Because a signal handler functions as an interrupt, it can only call reentrant code. You can’t call something as simple as printf safely, because printf could take a lock, and if there’s already an active call to printf on the thread where the handler runs, you’ll deadlock.

The sigaction man page gives a list of functions you are allowed to call from a signal handler. It’s pretty limited.

The complete list is: _exit(), access(), alarm(), cfgetispeed(), cfgetospeed(), cfsetispeed(), cfsetospeed(), chdir(), chmod(), chown(), close(), creat(), dup(), dup2(), execle(), execve(), fcntl(), fork(), fpathconf(), fstat(), fsync(), getegid(), geteuid(), getgid(), getgroups(), getpgrp(), getpid(), getppid(), getuid(), kill(), link(), lseek(), mkdir(), mkfifo(), open(), pathconf(), pause(), pipe(), raise(), read(), rename(), rmdir(), setgid(), setpgid(), setsid(), setuid(), sigaction(), sigaddset(), sigdelset(), sigemptyset(), sigfillset(), sigismember(), signal(), sigpending(), sigprocmask(), sigsuspend(), sleep(), stat(), sysconf(), tcdrain(), tcflow(), tcflush(), tcgetattr(), tcgetpgrp(), tcsendbreak(), tcsetattr(), tcsetpgrp(), time(), times(), umask(), uname(), unlink(), utime(), wait(), waitpid(), write(), aio_error(), sigpause(), aio_return(), aio_suspend(), sem_post(), sigset(), strcpy(), strcat(), strncpy(), strncat(), strlcpy(), strlcat().

Finally, the list ends with this amusing note: “…and perhaps some others.” “Perhaps” is not a nice word to run into in this sort of documentation.

You can call your own reentrant code, but you probably don’t have any, because it’s hard to write, it can’t call any system functions except from the above list, and you never had any reason to write it before. For the Objective-C types, note that objc_msgSend is not reentrant, so you cannot use any Objective-C from a signal handler.

There is very little that you can do safely. There is so little that I’m not even going to discuss how to get anything done, because it’s so impractical to do so, and instead will simply tell you to avoid using signal handlers unless you really know what you’re doing and you enjoy pain.

Fortunately, there are better ways to do these things.

kqueue One of those better ways is to use kqueue. This is a low level operating service which allows a program to monitor many different events, and one of the events it can monitor is signals. You can create a kqueue just for signal handling, or you can add a signal handling event to an existing kqueue you already have within your program.

Setting things up is a bit more involved, but all in all not too hard. First, the kqueue is created:

1
    int fd = kqueue();

1
    struct kevent event = { SIGUSR1, EVFILT_SIGNAL, EV_ADD, 0, 0 };
2
    kevent(fd, &event, 1, NULL, 0, NULL);

1
    struct sigaction action = { 0 };
2
    action.sa_handler = SIG_IGN;
3
    sigaction(SIGUSR1, &action, NULL);

1
    struct kevent event;
2
    int count = kevent(fd, NULL, 0, &event, 1, NULL);
3
    if(count == 1)
4
    {
5
        if(event.filter == EVFILT_SIGNAL)
6
            printf("got signal %d\n", (int)event.ident);
7
    }

kqueue isn’t always all that convenient to use in real programs, though. There are two reasonable ways to do it. One way is to have a dedicated signal handling thread which sits in a loop calling kevent repeatedly. Another way is to add the kqueue file descriptor to your runloop using something like CFFileDescriptor to integrate it with your Cocoa runloop. However neither of these is particularly great.

GCD Finally we reach a signal handling solution which is extremely easy to use: Grand Central Dispatch. In addition to the better-known multiprocessing capabilities, GCD also includes a full suite of event monitoring abilities which match those of kqueue. (And in fact, GCD implements them using kqueue internally.)

To handle a signal with GCD, we create a dispatch source to monitor the signal:

1
    dispatch_source_t source = dispatch_source_create(DISPATCH_SOURCE_TYPE_SIGNAL, SIGUSR1, 0, dispatch_get_global_queue(0, 0));

1
    dispatch_source_set_event_handler(source, ^{
2
        printf("got SIGUSR1\n");
3
    });
4
    dispatch_resume(source);

1
    struct sigaction action = { 0 };
2
    action.sa_handler = SIG_IGN;
3
    sigaction(SIGUSR1, &action, NULL);

That’s it! Every time a SIGUSR1 comes in, the handler is called. Because the source targets a global queue, the handler automatically runs in a background thread without interfering with anything else. If you prefer, you can give GCD a custom queue, or even the main queue, to control where the handler runs. Like with kqueue, because the handler runs normally on a normal thread, it’s safe to do anything in it that you would do in any other piece of code. GCD makes signal handling convenient, easy, and safe.

Conclusion Signal handling is a rare requirement, but sometimes useful. Using the low level sigaction to handle signals makes life unbelievably hard, as the signal handler is called in such a way as to place extreme restrictions on the code it contains. This makes it almost impossible to do anything useful in such a signal handler.

The best way to handle a signal in almost every case is to use GCD. Signal handling with GCD is easy and safe. On the rare occasions where you need to handle signals, GCD lets you do it with just a few lines of code.

If you can’t or don’t want to use GCD but still want to avoid sigaction, kqueue provides a good middle ground. While it’s more complicated to set up and manage than the GCD approach, it still works well to handle signals in a reasonable manner.

That wraps up today’s April Fool’s edition of Friday Q&A. Come back in two weeks for the next one. Until then, as always, keep sending me your ideas for topics. Friday Q&A is driven by reader suggestions, so if you have something you would like to see covered, send it in!
